In-house produced and developed rubber compounds form the core of the MC X Series’ mechanical damping system. Rubber dampers are essential for controlling the physical movement of the coils, maintaining stability, minimizing unwanted vibrations, and enabling precise coil motion. The result is superior tracking, reduced distortion, and musical accuracy.
Specifications
Channel balance at 1 kHz: 0.5 dB
Output voltage at 1 kHz, 5cm/sec: 0.4 mV
Channel separation at 1 kHz: 25 dB
Frequency response 20 Hz - 20 kHz: +/-1 dB
Compliance, dynamic, lateral: 15 μm/mN
Cantilever material: Aluminium
Stylus type: Nude Elliptical
Stylus tip radius: r/R 8/18 μm
Stylus suspensions: Ortofon exclusive
Coil system: Quad coils
Tracking force, recommended: 2.0 grams
Internal impedance, DC resistance: 6 Ω
Coil wire material: High-purity silver
Cartridge weight: 8.6 grams
Recommended load resistance: > 50 Ω
